GeoMesa Utils

Useful utilities are found in the geomesa-utils module.

Simple Feature Wrapper Generation

Tools can generate wrapper classes for simple feature types defined in TypeSafe Config files. Your config files should be under src/main/resources. Add the following snippet to your pom, specifying the package you would like the generated class to reside in:

<build>
    ...
    <plugins>
        ...
        <plugin>
            <groupId>org.codehaus.mojo</groupId>
            <artifactId>exec-maven-plugin</artifactId>
            <version>1.3.2</version>
            <executions>
                <execution>
                    <id>generate-sft-wrappers</id>
                    <phase>generate-sources</phase>
                    <goals>
                        <goal>java</goal>
                    </goals>
                    <configuration>
                        <mainClass>org.locationtech.geomesa.utils.geotools.GenerateFeatureWrappers</mainClass>
                        <cleanupDaemonThreads>false</cleanupDaemonThreads>
                        <killAfter>-1</killAfter>
                        <arguments>
                            <argument>${project.basedir}</argument>
                            <argument>org.foo.mypackage</argument>
                        </arguments>
                    </configuration>
                </execution>
            </executions>
        </plugin>
    </plugins>
</build>

Geohash

Geohashes are a geocoding system that uses a Z-order curve to hierarchically subdivide the latitude/longitude grid into progressively smaller bins. The length of a Geohash in bits indicates its precision.

For example, the table below shows Geohash bounding boxes around the point (-78.48, 38.03) with increasing levels of precision in units of bits (the coordinates are rounded to three decimal places for clarity):

bits

bounding box

centroid

geohash

1

-180.000 -90.000, 0.000 90.000

-90.000 0.000

0

2

-180.000 0.000, 0.000 90.000

-90.000 45.000

01

3

-90.000 0.000, 0.000 90.000

-45.000 45.000

011

4

-90.000 0.000, 0.000 45.000

-45.000 22.500

0110

5

-90.000 0.000, -45.000 45.000

-67.500 22.500

01100

6

-90.000 22.500, -45.000 45.000

-67.500 33.750

011001

7

-90.000 22.500, -67.500 45.000

-78.750 33.750

0110010

8

-90.000 33.750, -67.500 45.000

-78.750 39.375

01100101

9

-78.750 33.750, -67.500 45.000

-73.125 39.375

011001011

10

-78.750 33.750, -67.500 39.375

-73.125 36.563

0110010110

11

-78.750 33.750, -73.125 39.375

-75.938 36.563

01100101100

12

-78.750 36.563, -73.125 39.375

-75.938 37.969

011001011001

13

-78.750 36.563, -75.938 39.375

-77.344 37.969

0110010110010

14

-78.750 37.969, -75.938 39.375

-77.344 38.672

01100101100101

15

-78.750 37.969, -77.344 39.375

-78.047 38.672

011001011001010

16

-78.750 37.969, -77.344 38.672

-78.047 38.320

0110010110010100

17

-78.750 37.969, -78.047 38.672

-78.398 38.320

01100101100101000

18

-78.750 37.969, -78.047 38.320

-78.398 38.145

011001011001010000

19

-78.750 37.969, -78.398 38.320

-78.574 38.145

0110010110010100000

20

-78.750 37.969, -78.398 38.145

-78.574 38.057

01100101100101000000

21

-78.574 37.969, -78.398 38.145

-78.486 38.057

011001011001010000001

22

-78.574 37.969, -78.398 38.057

-78.486 38.013

0110010110010100000010

23

-78.486 37.969, -78.398 38.057

-78.442 38.013

01100101100101000000101

24

-78.486 38.013, -78.398 38.057

-78.442 38.035

011001011001010000001011

25

-78.486 38.013, -78.442 38.057

-78.464 38.035

0110010110010100000010110

The bounding boxes corresponding to the Geohashes in the table above are shown as red polygons on this map:

../../_images/geohash-cville.png

The org.locationtech.geomesa.utils.geohash.GeoHash class provides tools for working with Geohashes. The data for the table above may be generated with the following Scala code:

import org.locationtech.geomesa.utils.geohash.GeoHash

for (p <- 1 to 25) {
  val gh = GeoHash(-78.48, 38.03, p)
  println(s"""$p ${gh.bbox.toText} ${gh.getPoint.toText} ${gh.toBinaryString}""")
}

Base-32 Encoding

Geohashes are encoded as strings with the following base-32 representation:

dec

binary

base-32

dec

binary

base-32

0

00000

0

16

10000

h

1

00001

1

17

10001

j

2

00010

2

18

10010

k

3

00011

3

19

10011

m

4

00100

4

20

10100

n

5

00101

5

21

10101

p

6

00110

6

22

10110

q

7

00111

7

23

10111

r

8

01000

8

24

11000

s

9

01001

9

25

11001

t

10

01010

b

26

11010

u

11

01011

c

27

11011

v

12

01100

d

28

11100

w

13

01101

e

29

11101

x

14

01110

f

30

11110

y

15

01111

g

31

11111

z

By this convention, the 25-bit Geohash that contains (-78.48, 38.03) described above would be encoded as “dqb0q”:

01100 10110 01010 00000 10110
----- ----- ----- ----- -----
  d     q     b     0     q
